KILEMAS centrifugal barrel finishing machine produces sun-and-planet motion by the linkage of main shaft and barrel tub shafts to the pulleys. This machine can finish workpiece by the flow of contents in accordance with centrifugal force in the tubs by the revolution motion.
The machines in this series are general-purpose models with high-level controllability and operability made possible through the inverters, brake motors, and timing belts included as standard equipment.
Wear-resistant Polyurethane-lined contribute to long durability.
The models in this series are large-scale mass production machines.
In addition, at customer's request, it has a rich experience of a layout design with related equipment such as sorters, media return machines, and other machines.
Wear-resistant Polyurethane-lined contribute to long durability.
Model | Barrel Tub Capacity(ℓ) |
ID of Barrel Tub (mm) |
Motor (kW) |
Motor Circuit | Control Circuit | Footprint (mm) |
Overall Height (mm) |
---|---|---|---|---|---|---|---|
KCB-30 | 7×4tubs | 168 | 2.2 | Three-phase 380V(50Hz) |
AC220V | 1220×860 | 1200 |
KCB-80 | 19.5×4tubs | 223 | 5.5 | Three-phase 380V(50Hz) |
AC220V | 1700×1250 | 1720 |
