CENTRIFUGAL DISC FINISHING MACHINES

MACHINES

  • CENTRIFUGAL DISC FINISHING MACHINES
  • CENTRIFUGAL DISC FINISHING MACHINES
  • VIBRATORY BARREL FINISHING MACHINES

Representative machine of Post-Vibratory Barrel finishing

Excellent workability and shortening of finishing time

KILEMAS centrifugal disc finishing machine is formed of stationary barrel tub and spinning disc. It conducts finishing by swirling motion of contents of the tub generated by rotation of the spinning disc. This machine is categorized between centrifugal barrel finishing machines and vibratory barrel finishing machine. It can be easily automated.

KED Series Machines( Centrifugal Disc Finishing Machines )

KED Series Machines

KED Series Machines( Centrifugal Disc Finishing Machines )

With a compact size and work toward achieving the goal of incorporating basic performance, models in this series combine together high finishability and excellent workability.
Wear-resistant Polyurethane-lined contribute to long durability.

Optional Specifications
KED-J Series models are also available, which come with a Japanese motor and control panel as standard equipment.
Model

Barrel Tub

Capacity
(ℓ)

ID of

Barrel Tub
(mm)

Motor
(kW)

Motor Circuit Control Circuit Footprint
(mm)

Overall

Height
(mm)
KED-50 40 470 2.2

Three-phase

  380V(50Hz)
AC220V 1480×660 1240
KED-100 80 660 4.0

Three-phase

  380V(50Hz)
AC220V 1620×800 1370
PAGETOP

KED-250FA( Centrifugal Disc Finishing Machines )

KED-250FA Series Machines

KED-250FA( Centrifugal Disc Finishing Machines )

With the models in this series, all of the necessary processes for barrel finishing, from loading of materials, finishing, sorting, and simple cleaning, are completed automatically once the work piece has been set in the machine. Layout design of related equipment including work piece loading machines, rust inhibiting machines, and other machines can be completed easily as desired by the operators.
Wear-resistant Polyurethane-lined contribute to long durability.

Optional Specifications
KED-250FAJ models are also available, which come with a Japanese motor and control panel as standard equipment.
Model

Barrel Tub

Capacity
(ℓ)

ID of

Barrel Tub
(mm)

Motor
(kW)

Motor Circuit Control Circuit Footprint
(mm)

Overall

Height
(mm)
KED-250FA 240 830 7.5

Three-phase

380V(50Hz)
AC220V 2400×2100 1600
PAGETOP
Purpose of use (Centrifugal Disc Finishing Machines)
Centrifugal Disc Finishing Machiness will be able to achieve a wide range purpose by adjusting Abrasive medias, Compounds and the processing conditions.
That is Heavy grinding, radiusing, surface roughening, descaling, peeling of rust and weld spatter, deburring, smoothing, polishing, surface preparation of painting and plating, micro polishing, luster finishing, mirror finishing, peening, removing of surface stress and fatigue strength improvement.
