KILEMAS vibratory barrel finishing machine is linked with the vibratory motor and the tub through the springs.
It finishes workpieces by the flow of contents which caused by 3D vibration in accordance with the number of rotations. The advantages of the machine are high-volume- efficiency and high mass production.
Circle-type vibratory barrel finishing machine
With these models, 100% of the contents of the barrel tub can be used effectively, allowing for uniform finishing over a wide processing range. The machines in this series combine together a compact size with economic efficiency.
Wear-resistant Polyurethane-lined contribute to long durability.
Model | Barrel Tub Capacity(ℓ) |
ID of Barrel Tub (mm) |
Height of Discharge Door (mm) |
Vibratory Motor(kW) |
Motor Circuit | Control Circuit |
Footprint (mm) |
Overall Height (mm) |
---|---|---|---|---|---|---|---|---|
KVT-100 | 75 | 215 | 520 | 1.5 | Three-phase 380V(50Hz) |
AC220V | 970×970 | 1060 |
KVT-200 | 165 | 275 | 460 | 2.2 | Three-phase 380V(50Hz) |
AC220V | 1350×1370 | 1010 |
KVT-200H | 165 | 275 | 605 | 3.0 | Three-phase 380V(50Hz) |
AC220V | 1340×1340 | 1100 |
KVT-600 | 480 | 380 | 630 | 5.5 | Three-phase 380V(50Hz) |
AC220V | 1850×1850 | 1250 |
※Footprint doesn't include the self-supporting operation panel.
Circle-type vibratory barrel finishing machine equipped with separating feature. Models in this series, designed for use in batch processing, come with a vibratory barrel that is equipped with a sorting feature in the main unit. This setup enables every step of the finishing process, from finishing to simple water-based washing and sorting, to be completed by a single machine. Layout design of related equipment needed at points in front of or behind the main unit in the system is easy.
Wear-resistant Polyurethane-lined contribute to long durability.
Model | Barrel Tub Capacity(ℓ) |
ID of BarrelTub (mm) |
Height of SeparatorExit (mm) |
Height of |
Vibratory Motor(kW) |
Motor Circuit | Control Circuit |
Footprint (mm) |
Overall Height(mm) |
---|---|---|---|---|---|---|---|---|---|
KVTS-100 | 70 | 235 | 810 | 480 | 1.5 | Three-phase 380V(50Hz) |
AC220V | 1140×1100 | 1060 |
KVTS-100H | 75 | 235 | 900 | 490 | 2.2 | Three-phase 380V(50Hz) |
AC220V | 1250×1200 | 1180 |
KVTS-200 | 130 | 275 | 950 | 585 | 2.2 | Three-phase 380V(50Hz) |
AC220V | 1300×1450 | 1180 |
KVTS-600 | 350 | 370 | 1140 | 570 | 5.5 | Three-phase 380V(50Hz) |
AC220V | 1850×1850 | 1300 |
※Footprint doesn't include the self-supporting operation panel.
